Console: The QUANTUM series consoles utilize advanced digital and high-IF technologies, featuring a highly integrated transceiver design. This enables high-precision, high-speed control of RF frequency, phase, and amplitude, supporting reliable long-term experiments with complex pulse sequences.
Magnet: AS400Pro, featuring high magnetic field homogeneity, low magnetic field drift (≤4Hz/hour), ultra-shielding (0.6m), and extended liquid helium hold time (≥280 days).
Probe: STM (Smart Tune & Match) intelligent tuning broadband probe, supporting fast tuning/matching and a wide VT range. Optimized for heteronuclei, both high-band and broadband channels can be tuned to 19F nuclei, enabling a wide range of 19F-related experiments.
Magnet Control System: Equipped with a digital shim and lock system, it ensures stability for high-resolution experiments. The RT shim system consists of 32 shim channels and supports 1D and3D automatic gradient shimming.
Software: The professional NMR software SpinStudioJ is dedicated for spectrometer control, pulse sequence programming, data acquisition and processing. It features a user-friendly interface and supports Chinese and English.
Autosampler: Optional 24-position and 60-position models, featuring fast sample loading speed, lightweight design, and easy installation and maintenance.
