Console: The QUANTUM series consoles utilize advanced digital and high-IF technologies, featuring a highly integrated transceiver design. This enables high-precision, high-speed control of RF frequency, phase, and amplitude, supporting reliable long-term experiments with complex pulse sequences. It is expandable to multiple-channels for multi-nuclear and multi-dimensional NMR experiments.
Magnet: The AS600Pro magnet features high magnetic field homogeneity, low magnetic field drift, and ultra-shielding.
Probe: The STM (Smart Tune & Match) intelligent tuning broadband probe provides high-sensitivity inverse detection of ¹H nuclei and direct observation of low-frequency nuclei. It features two performance modes and supports fast tuning as well as wide-range tuning.
Shim: The digital shimming system meets the requirements for stable, high-resolution experiments. It is equipped with ≥39 sets of room-temperature shimming coils and supports 1D and 3D automatic gradient shimming.
Software: The professional NMR software SpinStudioJ supports spectrometer control, pulse sequence editing, data acquisition, and processing. Its user interface is intuitive and allows for Chinese-English switching.
Auto - sampler: Optional 24 - position and 60 - position samplers, with fast sample loading speed, lightweight design, easy installation and maintenance.
